New Press Machines
KOMATSU H2W
Independent 2-axis servo drive maintains slide parallelism with high precision, improving productivity and forming accuracy.
Single-Shot ProcessingProgressive ProcessingTransfer ProcessingPrecision General Purpose
Specifications
H2W200-S
- Type
- S
- Frame Shape
- Straight Side
- Capacity(kN)
- 2000
- Stroke(mm)
- 250
- SPM(spm)
- 〜50
- Die Height(mm)
- 500
- Die Height Adjustment(mm)
- 120
- Slide Size(mm)
- 1850×650
- Bed Size(mm)
- 2150×850
| Type | S |
|---|---|
| Frame Shape | Straight Side |
| Capacity(kN) | 2000 |
| Stroke(mm) | 250 |
| SPM(spm) | 〜50 |
| Die Height(mm) | 500 |
| Die Height Adjustment(mm) | 120 |
| Slide Size(mm) | 1850×650 |
| Bed Size(mm) | 2150×850 |
H2W200-H
- Type
- H
- Frame Shape
- Straight Side
- Capacity(kN)
- 2000
- Stroke(mm)
- 150
- SPM(spm)
- 〜85
- Die Height(mm)
- 500
- Die Height Adjustment(mm)
- 120
- Slide Size(mm)
- 1850×650
- Bed Size(mm)
- 2150×850
| Type | H |
|---|---|
| Frame Shape | Straight Side |
| Capacity(kN) | 2000 |
| Stroke(mm) | 150 |
| SPM(spm) | 〜85 |
| Die Height(mm) | 500 |
| Die Height Adjustment(mm) | 120 |
| Slide Size(mm) | 1850×650 |
| Bed Size(mm) | 2150×850 |
H2W300-S
- Type
- S
- Frame Shape
- Straight Side
- Capacity(kN)
- 3000
- Stroke(mm)
- 350
- SPM(spm)
- 〜30
- Die Height(mm)
- 600
- Die Height Adjustment(mm)
- 200
- Slide Size(mm)
- 2100×900
- Bed Size(mm)
- 2400×1200
| Type | S |
|---|---|
| Frame Shape | Straight Side |
| Capacity(kN) | 3000 |
| Stroke(mm) | 350 |
| SPM(spm) | 〜30 |
| Die Height(mm) | 600 |
| Die Height Adjustment(mm) | 200 |
| Slide Size(mm) | 2100×900 |
| Bed Size(mm) | 2400×1200 |
H2W300-H
- Type
- H
- Frame Shape
- Straight Side
- Capacity(kN)
- 3000
- Stroke(mm)
- 170
- SPM(spm)
- 〜65
- Die Height(mm)
- 600
- Die Height Adjustment(mm)
- 200
- Slide Size(mm)
- 2100×900
- Bed Size(mm)
- 2400×1200
| Type | H |
|---|---|
| Frame Shape | Straight Side |
| Capacity(kN) | 3000 |
| Stroke(mm) | 170 |
| SPM(spm) | 〜65 |
| Die Height(mm) | 600 |
| Die Height Adjustment(mm) | 200 |
| Slide Size(mm) | 2100×900 |
| Bed Size(mm) | 2400×1200 |
| Model | H2W200-S | H2W200-H | H2W300-S | H2W300-H |
|---|---|---|---|---|
| Type | S | H | S | H |
| Frame Shape | Straight Side | Straight Side | Straight Side | Straight Side |
| Capacity(kN) | 2000 | 2000 | 3000 | 3000 |
| Stage Capacity(kN) | - | - | - | - |
| Stroke(mm) | 250 | 150 | 350 | 170 |
| SPM(spm) | 〜50 | 〜85 | 〜30 | 〜65 |
| Die Height(mm) | 500 | 500 | 600 | 600 |
| Die Height Adjustment(mm) | 120 | 120 | 200 | 200 |
| Shank Hole Diameter(mm) | - | - | - | - |
| Slide Size(mm) | 1850×650 | 1850×650 | 2100×900 | 2100×900 |
| Bed Size(mm) | 2150×850 | 2150×850 | 2400×1200 | 2400×1200 |
| Feed Stroke(mm) | - | - | - | - |
| Clamp Stroke(mm) | - | - | - | - |
| Feed Bar Spacing(mm) | - | - | - | - |
